PVC-Coated Galvanized Welded Wire Mesh for Plant Protection

Imagem Grande : PVC-Coated Galvanized Welded Wire Mesh for Plant Protection

Detalhes do produto:

Lugar de origem:	China
Marca:	QiJie
Certificação:	ISO9001:2008, SGS, CE
Número do modelo:	01WWM

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	50 rolos
Preço:	USD9.90-USD45.90
Detalhes da embalagem:	Película de plástico ou papel à prova d'água
Tempo de entrega:	10-25 dias
Termos de pagamento:	TT, LC,
Habilidade da fonte:	1000 rolos/dia

Contato

Descrição de produto detalhada

Material:	fio de aço carbono	Abertura de malha:	12 × 12, 20 × 20, 25 × 25, 12 × 25 mm
Diâmetro do fio:	0.4mm - 1.5mm	Largura do rolo:	0.4m, 0.5m, 0.6m, 0.8m, 1.0m, 1.25m, 1.5m, 2.0m
Comprimento do rolo:	15M, 30M, ect de 50M	Tratamento de superfície:	Quente mergulhado galvanizado ou elétrico galvanizado
Número do modelo:	XX-01001	Aplicativo::	Malha de cerca
E-mail:	devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Destacar:	PVC coated welded wire mesh , galvanized plant protection mesh , welded wire mesh for gardens

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection

Product Description:

Galvanized Welded Wire Mesh is a high-performance metal mesh made by welding high-quality low-carbon steel wires into regular grids, then undergoing hot-dip or electro-galvanization. The galvanized layer provides strong corrosion resistance, while the welded structure ensures stability, making it suitable for long-term indoor and outdoor use.

Galvanized Welded Wire Mesh boasts outstanding durability and structural reliability. Its galvanized coating—especially the hot-dip galvanized layer—forms a dense protective barrier on the steel wire surface, effectively resisting corrosion from air, moisture, and weak corrosive media, allowing outdoor service life of 10-20 years.

Each wire intersection is firmly fixed by resistance welding, ensuring the mesh remains stable without loosening or deformation even under external pressure, and its automated production guarantees precise, uniform mesh sizes for consistent performance in various scenarios.

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 0

Applications:

Plaster mesh is widely used as a reinforcing material to protect the internal and external walls,floors and ceilings against cracking in the industrial plants and other architectures.Plaster Welded Wire Mesh has a wide scope. It can be used for the building inside and outside plaster reinforcement. As an essential piece of plastering work, it creates lasting plaster coating for absolutely all surfaces of concrete and brick to wood, and even plaster ceilings. Before plastering, the welded mesh must be mounted on wall by a solid dowel-nails or anchor bolts, which makes the plaster work easier. The Plaster Welded Wire Mesh makes the plaster wall surface smooth and no crack, also excludes the impact of external factors on the wall.

Specification

Opening		Wire Diameter
In inch	In metric unit	Wire Diameter
1/4" x 1/4"	6.4 x 6.4mm	BWG24-22
3/8" x 3/8"	10.6x 10.6mm	BWG22-19
1/2" x 1/2"	12.7 x 12.7mm	BWG23-16
5/8" x 5/8"	16.0x 16.0mm	BWG21-18
3/4" x 3/4"	19.1 x 19.1mm	BWG21-16
1" x 1/2"	25.4x 12.7mm	BWG21-16
1-1/2" x 1-1/2"	38.0 x 38.0mm	BWG19-14
1" x 2"	25.4 x 50.8mm	BWG16-14
2" x 2"	50.8 x 50.8mm	BWG15-12
2" x 4"	50.8 x 101.6mm	BWG15-12
4" x 4"	101.6 x 101.6mm	BWG15-12
4" x 6"	101.6 x 152.4mm	BWG15-12
6" x 6"	152.4 x 152.4mm	BWG15-12
6" x 8"	152.4 x 203.2mm	BWG14-12
Roll Width: 0.5m-2m; Roll Length: 5m, 10m, 30m, etc.
Material: galvanized, PVC coated, stainless steel.
Note: Special specifications can be made according to customers requires.

Product application

Widely used in industry, agriculture, construction, transportation, mining, and other industries. Such as machine protective hoods, beasts and animal fences, window fences, channel fences, poultry cages, paper baskets, and decorations.

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 1

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 3

Specification
Opening		Wire Diameter	Width 0.4-2m Length 5-50m	electric galvanized before welded, electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire
Inch	Metric Unit	Wire Diameter
1/4"x1/4"	6.4mmx6.4mm	BWG24-22
3/8"x3/8"	10.6mmx10.6mm	BWG22-19
1/2"x1/2"	12.7mmx12.7mm	BWG23-16
5/8"x5/8"	16mmx16mm	BWG21-18
3/4"x3/4"	19.1mmx19.1mm	BWG21-16
1"x1/2"	25.4mmx25.4mm	BWG21-16
1-1/2"x1 1/2"	38mmx38mm	BWG19-14
1"x2"	25.4mmx12.7mm	BWG16-14
2"x2"	50.8mmx50.8mm	BWG15-12
2"x4"	101.6mmx101.6mm	BWG15-12
4"x4"	101.6mmx152.4mm	BWG15-12
4"x6"	101.6mmx152.4mm	BWG15-12
6"x6"	152.4mmx152.4mm	BWG15-12
6"x8"	15.4mmx203.2mm	BWG14-12
Note:Special specification can be made according to customers requires

SURFACE TREATMENT

1.Electrical zinc coating mesh

First welding,cutting the edge of the panel which can make sure the edges is smooth and not hurt your hands,clectrical zinc coating,packing

2.Pre Galvanized mesh

Use the hot dip gal. wire direct do the welding,cutting the edge of the panel which can make sure the edge is smooth and not hurt your hands,packing

3.Hot dip galvanized mesh

First welding,cutting the edge of the panel which can make sure the edges is smooth and not hurt your hands,clectrical zinc coating,packing

4.PVC coated welded wire mesh
Black wire + PVC coated
Galvanized wire+PVC coated

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 5

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 6

Feature of plastering welded wire mesh:

1. economic and good looking

2. anti-corrosion and long service life

3. wide scope of using

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 7

Welded Wire Mesh Welding style:

Hot dipped galvanized after or before welding

Electro galvanized after or before welding

Weaving and characteristics:

Hot dipped galvanizing after welding

Welding with hot dipped galvanized iron wire

Electric galvanizing after welding

Welding with electric galvanized iron wire

PVC coated welded wire mesh

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 8

PVC-Coated Galvanized Welded Wire Mesh for Plant Protection 10

Qijie Wire Mesh MFG Co.,ltd is a professional manufacturer of fences, wire mesh products with more than 20 years experience. Welcome to visit our factory located in Anping city at any time!
